Impact Crushing and Screening Plant TX2IE
Integrated Crushing and Screening,Dual-Power (Diesel and Electric),PLC One-Touch Smart Start
The TX2IE is the high-efficiency king in the field of track-mounted mobile crushing and screening for medium-hard rock. It integrates three core units—a vibrating feeder, a cone crusher, and a two-deck dual-stage screen—to achieve the same crushing and screening performance as a separate production line. Furthermore, it is equipped with an independent pre-screening device to further enhance crushing efficiency. It has also been upgraded to a hybrid (diesel-electric) power system, allowing for a one-touch start to begin production as soon as it arrives on site.
Application scenarios: secondary and tertiary crushing and screening of medium and high hardness materials, secondary crushing and screening of hard rocks (granite/basalt/cobblestone/diabase, etc.).
Processing capacity:
150-250 （t/h）
Total system power:
325.3 （KW）
Service hotline:
Product Details
Product Specifications
Whole plant model | Weight (T) | Power of complete machine (KW) | Crusher model | Crusher size | Optional |
TX2IE | 65 | 325.3 | PF1213 | 1200*1300 | Three-deck screening、Double-side discharge belt conveyor、Oil and electricity dual-purpose system 400kw Power system |
