Powerful Function,Excellent Product Shape,High Energy Efficiency Ratio

Midas MI series tracked mobile impact crushing plant, each module is compact and efficient, many places are assisted by hydraulic pressure, equipped with return screening system, in addition, iron removal air separation spray device, can do primary and secondary crushing, suitable for medium soft rock and construction waste. The machine delivers stable performance, is easy to move between sites, and provides a superior particle shape.


Application scenarios: primary and secondary crushing stages of medium soft and hard materials, mine ore crushing, construction waste recycling, construction aggregate production, highway/railway, road and bridge construction.


Processing capacity:

100-600 (t/h)

Total system power:

217.2-415.7 (KW)

Product Details

MI系列反击式破碎站



Midas MI series tracked mobile impact crushing plant, each module is compact and efficient, many places are assisted by hydraulic pressure, equipped with return screening system, in addition, iron removal air separation spray device, can do primary and secondary crushing, suitable for medium soft rock and construction waste. The machine delivers stable performance, is easy to move between sites, and provides a superior particle shape.



Midas

Product Specifications

Whole plant model

Weight (T)

Power of complete machine (KW)

Crusher model

Crusher size

Optional

MI260R

55

309.7

M1213

1200*1300

Grizzly feeder、Side discharge conveyor、Return system

MI260RE

57

309.7

M1213

1200*1300

Oil and electricity dual-purpose system 400kw Power system

MI350R

63

339.7

M1315

1300*1500

Grizzly feeder、Side discharge conveyor、Return system

MI350RE

66

339.7

M1315

1300*1500

Oil and electricity dual-purpose system 500kw Power system

MI450R

65

375.7

M1415

1400*1500

Grizzly feeder、Side discharge conveyor、Return system

MI450RE

68

375.7

M1415

1400*1500

Oil and electricity dual-purpose system 500kw Power system

Relevant Cases

Crushing of bridge cutting blocks

Crushing of bridge cutting blocks

Crushing of old road pavement

Crushing of old road pavement

Crushing of old road pavement

Crushing of old road pavement

Crushing of old road pavement

Crushing of old road pavement
